Vault Agent Scheduler for AirGap for Dell
Introduction
The Vault Agent Scheduler provides an additional layer of security for AirGap job scheduling by moving control from Eyeglass into the secure Vault Agent. When this mode is enabled, job schedules can no longer be viewed or modified from Eyeglass. This reduces the risk of accidental or unauthorized changes that could impact replication operations.
Administrators can choose between Vault Control mode (schedules managed entirely within the Vault Agent) and the default Eyeglass Control mode. This setting applies cluster-wide across all Vault Agents and must be consistent to ensure correct operation.
This guide explains how to enable Vault Control mode, how to manage schedules securely from the Vault Agent, and what changes to expect in system behavior and UI access. It includes step-by-step configuration instructions, command references, and details about schedule synchronization, maintenance window limitations, and further UI visibility controls.
Requirements
- Version 2.11.0 or Later
- All Vault Agents in the cluster must use the same scheduling mode (Vault Control mode or Eyeglass Control mode)
- Confirm SSH access to both the Vault Agent(s) and Eyeglass
Configuration Steps
Follow these steps to enable Vault Control mode. The scheduling mode must be consistent across all Vault Agents connected to Eyeglass.
-
Check the current scheduling mode
On all Vault Agents and on Eyeglass, run the appropriate command to view whether scheduling is being handled by Eyeglass or by the Vault Agent.
# Vault Agent
ecactl airgap invaultschedule
# Eyeglass
igls airgap invaultscheduleIf the command returns
true, scheduling is managed in the vault.
If the command returnsfalse, scheduling is managed in Eyeglass (default).The default value is false.
-
Set Vault Control mode
On all Vault Agent nodes and on Eyeglass, run the appropriate command to enable Vault Control mode by setting the flag value to true. The default value is false.
# Vault Agent
ecactl airgap invaultschedule --set true
# Eyeglass
igls airgap invaultschedule set --value=trueEyeglass updates the flag after the next vault heartbeat; allow up to one minute for the change to appear in the UI.
importantYou must set the flag on every Vault Agent and on Eyeglass.
If the flags do not match, schedule‑related operations fail:
- Vault Agent cannot retrieve jobs.
- Eyeglass logs an error or shows inconsistent status.
Eyeglass triggers an alarm, which states
Vault-Controlled Scheduling settings is not sychronized with vault agent. -
Verify scheduling mode
Run the commands from step 1 again. Both Vault Agent and Eyeglass should report
true, confirming that scheduling is being managed from the vault.If you want to keep Eyeglass‑controlled scheduling, leave the flag set to
falseon every Vault Agent and on Eyeglass.
Vault Control Operations
When Vault Control mode is enabled, you manage all schedules and several operations exclusively on the Vault Agent.
List jobs and schedules from the Vault Agent
Use the following command to list jobs and schedule details from the Vault Agent.
ecactl airgap listJobs --source=local
Use --source=eyeglass to compare against the list stored in Eyeglass.
